| 品牌：日本NICHIFU | 型号：TMEV 2Y-3.5S | 种类：FFC/FPC |
| 应用范围：LED | 工作频率：低频 | 接口类型：1394 |
| 形状：矩形 | 线长：TMEV 2Y-3.5S mm | 制作工艺：冷压 |
| 加工定制：否 | 特性：防爆 | 接触件材质：TMEV 2Y-3.5S |
| 绝缘体材质：TMEV 2Y-3.5S | 芯数：TMEV 2Y-3.5S | 针数：TMEV 2Y-3.5S |
| 订货号：TMEV 2Y-3.5S | 物料编号：TMEV 2Y-3.5S | 最小包装数：1 |
| 是否跨境货源：否 | 货号：TMEV 2Y-3.5S | 应用领域：3C数码 |
***销售PC型 端子(PC2005-F)的详细描述：
此价格不代表实际价格 如需报价 请旺旺联系或来电
联系人：查保权 手 机： 15195777125 直销QQ: 1018834662
| 商品コード | 品番 | 各部の寸法（mm） | ||||||
| φd2 | B | L | F | E | φD | φd | ||
| 101857 | 1.25Y-3.5K | 3.7 | 5.6 | 15 | 5.8 | 4.5 | 3.4 | 1.7 |
| 101858 | 0.3Y-3.5N | 3.7 | 5.8 | 15 | 5.8 | 4.5 | 2.2 | 1 |
| 101859 | 1.25Y-3 | 3.2 | 5.8 | 15 | 5.8 | 4.5 | 3.4 | 1.7 |
| 101860 | 1.25Y-3N | 3.2 | 5.8 | 16 | 6.6 | 4.5 | 3.4 | 1.7 |
| 101861 | 1.25Y-3L | 3.7 | 6.2 | 16 | 6.8 | 4.5 | 3.4 | 1.7 |
| 101862 | 1.25Y-3S | 3.2 | 5.7 | 11.9 | 4.8 | 4.5 | 3.4 | 1.7 |
| 101863 | 1.25Y-3.5 | 3.7 | 5.8 | 15 | 5.8 | 4.5 | 3.4 | 1.7 |
| 101864 | 1.25Y-4N | 4.3 | 6.4 | 16.4 | 6.6 | 4.5 | 3.4 | 1.7 |
| 101865 | 1.25Y-4S | 4.3 | 7 | 16.4 | 7.6 | 4.5 | 3.4 | 1.7 |
| 101866 | 1.25Y-4M | 4.3 | 8.1 | 16.4 | 7.5 | 4.5 | 3.4 | 1.7 |
| 101867 | 1.25Y-5 | 5.3 | 9.6 | 17.5 | 8.3 | 4.5 | 3.4 | 1.7 |
| 101868 | 2Y-3 | 3.2 | 5.9 | 15.8 | 6.6 | 4.5 | 4.2 | 2.3 |
| 101869 | 2Y-3.5 | 3.7 | 6.4 | 15.8 | 6.6 | 4.5 | 4.2 | 2.3 |
| 101870 | 2Y-3.5S | 3.7 | 5.8 | 15.8 | 6.6 | 4.5 | 4.2 | 2.3 |
| 101871 | 2Y-4N | 4.3 | 6.4 | 16 | 6.6 | 4.5 | 4.2 | 2.3 |
| 101872 | 2Y-4S | 4.3 | 7 | 16 | 7 | 4.5 | 4.2 | 2.3 |
| 101873 | 2Y-4 | 4.3 | 8 | 16 | 7.1 | 4.5 | 4.2 | 2.3 |
| 101874 | 2Y-5 | 5.3 | 8 | 16 | 7.1 | 4.5 | 4.2 | 2.3 |
| 101875 | 3.5Y-4 | 4.3 | 8 | 18 | 7.2 | 6 | 5 | 3 |
| 101876 | 3.5Y-5 | 5.3 | 9.5 | 20 | 8.3 | 6 | 5 | 3 |
| 101877 | 3.5Y-6 | 6.4 | 12 | 22 | 9.8 | 6 | 5 | 3 |
| 101878 | 5.5Y-4 | 4.3 | 9 | 18.2 | 7.2 | 6.5 | 5.6 | 3.4 |
| 101879 | 5.5Y-5 | 5.3 | 9 | 18.2 | 7.2 | 6.5 | 5.6 | 3.4 |
| 101880 | 5.5Y-6 | 6.4 | 12.5 | 25.2 | 12 | 6.5 | 5.6 | 3.4 |
| 101881 | 8Y-5 | 5.3 6.4 | 12 | 24 | 8.3 | 8.4 | 7.1 | 4.5 |
| 101882 | 8Y-6 | 5.3 6.4 | 12 | 24 | 8.3 | 8.4 | 7.1 | 4.5 |
